Cadence Allegro and OrCAD 2022.1 HF011 (22.10.011)
Cadence Allegro and OrCAD 2022.1 HF011 (22.10.011) | 4.0 Gb
Cadence Design Systems, Inc. , the leader in global electronic design innovation, is pleased to announce the availability of Cadence Allegro and OrCAD 2022.1 HF011 families of products aimed at boosting performance and productivity through improvements features and big fixed issues.
Cadence OrCAD and Allegro: What’s New in Release 22.1
The bellow presents sections describes the new features and enhancements in Allegro PCB Editor and Allegro Package Designer Plus, in release 22.1.
- Memory Usage and Performance Improvement Using 3DX Canvas
- High-Speed Structure Enhancements
. Parameterized High-Speed Structures
. Differential Pair Vias Replaced by Structures
. On-Canvas Structure Update and Variant Creation
- Converting Shapes, Vias, and Pins
- Dimensioning Update
- Route Keepouts Exception Use Model Enhancement
- Performance Enhancements
. Better Performance in Designs with Large Number of DRCs
. Faster Update to Smooth
. Better Move Performance
. Better Performance for Shape Parameter per Layer Override
. Restricting Command Window Messages
. Faster DRC Checking on Designs with Negative Layers
Migrating to Release 22.1
Although the database format has not changed between releases 17.4-2019 and 22.1, you still need to acquire new licenses and an account to work with Mirrored Layers.
Database Format
You can open any release 17.4-2019 design in release 22.1 or, conversely, a release 22.1 design in release 17.4-2019 without any need to migrate the database format because the same database format is used across the two releases.
The 17.2 Database Compatibility Mode can still be enabled in User Preferences Editor to allow release 17.2 designs to be opened in releases 17.4 or 22.1 without updating the database version. Designs opened in the compatibility mode can be opened in release 17.2.
Cadence Allegro and OrCAD 2022.1 HF011 (22.10.011)
License Updates
A new license file is required to run release 22.1 products. Products from earlier releases such as 17.x, can also be opened with a release 22.1 license.
Structures and Vias in Mirrored Layers
If a database has structures in the mirrored layers state, that is marked as mirrored_layers, the database cannot be migrated to a version earlier than release 17.4 -2019, HotFix 028 (QIR4). The objects in the mirrored layers state are structures that are flipped using the Mirror Geometry command and then mirrored to the opposite side of the board. It is common to use the Mirror Geometry command to flip a structure on the same layer, but vias can also be flipped when moved or copied and if such vias are part of a symbol, module, or group, mirroring changes the vias to the Mirrored Layers state.
2918537 ALLEGROX DATABASE Import netlist adds incorrect ALT_SYMBOL property to symbol
2974010 ALLEGROX DATABASE Reading in schematic in a MDD file does not change footprint
2867505 ALLEGROX DFA Object Report in ConsMgr fails to output some of DFM constraints
2979926 ALLEGROX DFA DFA PkgToPkg Spacing Constraint Bug: Delete/Purge symbols will reset its constraints in other CM sets.
1566989 ALLEGROX DFM Add DRC check for actual drill bit size for plated hole/slot padstacks
2058669 ALLEGROX DFM 'Spacing Hole to' to show Drill Hole Size (DHS) instead of Finished Hole Size (FHS)
2259992 ALLEGROX DFM Allow drill to metal DRC check to use Drill tool size specified in the padstack editor instead of FHS drill size
2517674 ALLEGROX DFM Align drill tool size with database units and accuracy
2779490 ALLEGROX DFM Enhance Drill chart table to suppress display of finished hole size when drill tool size is present
2923420 ALLEGROX EXTRACT Support for etch factor in extracta output
2959321 ALLEGROX GRAPHICS Drill Labels for Slotted Via Padstacks are too large when the slot is rotated
2984301 ALLEGROX GRAPHICS The fixed objects are invisible when GPU enabled.
3013091 ALLEGROX GRAPHICS Slot Drill Figure Wrong Rotation
2885735 ALLEGROX MODULES The connection is broken by create module.
2688929 ALLEGROX PULSE Enable Pulse access when launching Allegro PCB Editor with an Aurora or Aurora II license
2995285 ALLEGROX PULSE How to clear Pulse ID from a board file?
2728246 ALLEGROX SHAPE Static shape same net DRC cannot be removed automatically
2996757 ALLEGROX SHAPE Incorporate release 22.1 HotFix 004 shape behavior in Dyn_Shape_Legacy for release 22.1 HotFix 009
2954798 APD DRC_CONSTRAIN Find & replace function in CM causes a crash
2971983 APD INTERACTIVE Results of Find by Query is incorrect in version 22.1 HF-8
2178156 APD REPORTS Remove the # character for the pins that have duplicate names in the component pin report
2990687 CONCEPT_HDL CORE The 'nconcepthdl' script command takes a long time to complete
2991711 CONCEPT_HDL CORE Saving takes an extreme amount of time
2993105 CONSTRAINT_MGR OTHER Crash with IPC SKILL calls
2997499 CONSTRAINT_MGR OTHER System Capture crashes when user opens CM
3030810 CONSTRAINT_MGR SYSCAP System Capture crashes when you click on a Voltage property that has a conflict (Red) indicator
2860787 PULSE DASHBOARD Medic testcase generation failing (Error: C:/Windows/TEMP/history does not exist)
2826304 PULSE R2PLM-LIBSYNC Need ability to push part level attribute values from Windchill to Pulse Managed Library.
3006874 PULSE R2PLM-LIBSYNC PFM Libsync request to also sync "business group" attributes
2896520 PULSE R2PLM Unable to configure SSO due to hardcoded URL params for Pingfed
2930064 PULSE R2PLM Enable SSO support for Windows Active directory using ADFS for R2PLM
2989057 SYSTEM_CAPTURE CONSTRAINT_MA System Capture crashes when cross-probing from Constraint Manager
2994854 SYSTEM_CAPTURE CONSTRAINT_MA Slowness issue- Editing the blocks in mastermode hangs the syscap
3014399 SYSTEM_CAPTURE DRC Export CSV from Schematic audit report wraps columns for Waived Violation Section
3035989 SYSTEM_CAPTURE FIND_REPLACE Find and Modify netname causes some pins to be disconnected
3036008 SYSTEM_CAPTURE FIND_REPLACE System Capture Find and Replace net names cause many pins to be disconnected
2775636 SYSTEM_CAPTURE HSS_DESIGNEDI system capture: mismatch reported on interface ports of netgroups with correct hierarchy
2587472 SYSTEM_CAPTURE PACKAGER In System Capture SLD, package option for blocks should not be available
2903688 SYSTEM_CAPTURE PACKAGER Undo does not undo refdes change from replacing multi-gate part
3030808 SYSTEM_CAPTURE PACKAGER When Packaging options in System Capture cursor behaviour needs to be changed
3045237 SYSTEM_CAPTURE PACKAGER RMB on functional block > "Packaging Options…" in project explorer window causes Syscap crash
3004270 SYSTEM_CAPTURE PART_MANAGER Unison confirmation popup when updating out of sync parts in Part Manager
3011987 SYSTEM_CAPTURE PART_MANAGER Part manager shows parts in manual sync while property panel shows the parts in sync
2946498 SYSTEM_CAPTURE SYMBOL_GEN Position of some wires in DE-HDL design moved from original location after design migration to System Capture
3047762 SYSTEM_CAPTURE SYMBOL_GEN Importing design from DEHDL to Syscap has error- DSCS-1036 errors.
2985507 SYSTEM_CAPTURE UI In 22.1 ISR009 SysCap shifts position of Navlinks
2947758 SYSTEM_CAPTURE UNIFIED_SEARC Part Number column in Unified Search is hidden when window is undocked and resized
2815584 SYSTEM_DESIGN SDE_EXPORT_SU Subsystems project cannot be exported when site.cpm sets user page border
3001872 SYS_RELIABILITY STRESS_ANALYS Stress analysis is ignoring the part based on BOM_IGNORE property irrespective of its value.
2990723 TDA CORE ALGX300 cannot invoke Team Design Authoring
2974010 ALLEGROX DATABASE Reading in schematic in a MDD file does not change footprint
2867505 ALLEGROX DFA Object Report in ConsMgr fails to output some of DFM constraints
2979926 ALLEGROX DFA DFA PkgToPkg Spacing Constraint Bug: Delete/Purge symbols will reset its constraints in other CM sets.
1566989 ALLEGROX DFM Add DRC check for actual drill bit size for plated hole/slot padstacks
2058669 ALLEGROX DFM 'Spacing Hole to' to show Drill Hole Size (DHS) instead of Finished Hole Size (FHS)
2259992 ALLEGROX DFM Allow drill to metal DRC check to use Drill tool size specified in the padstack editor instead of FHS drill size
2517674 ALLEGROX DFM Align drill tool size with database units and accuracy
2779490 ALLEGROX DFM Enhance Drill chart table to suppress display of finished hole size when drill tool size is present
2923420 ALLEGROX EXTRACT Support for etch factor in extracta output
2959321 ALLEGROX GRAPHICS Drill Labels for Slotted Via Padstacks are too large when the slot is rotated
2984301 ALLEGROX GRAPHICS The fixed objects are invisible when GPU enabled.
3013091 ALLEGROX GRAPHICS Slot Drill Figure Wrong Rotation
2885735 ALLEGROX MODULES The connection is broken by create module.
2688929 ALLEGROX PULSE Enable Pulse access when launching Allegro PCB Editor with an Aurora or Aurora II license
2995285 ALLEGROX PULSE How to clear Pulse ID from a board file?
2728246 ALLEGROX SHAPE Static shape same net DRC cannot be removed automatically
2996757 ALLEGROX SHAPE Incorporate release 22.1 HotFix 004 shape behavior in Dyn_Shape_Legacy for release 22.1 HotFix 009
2954798 APD DRC_CONSTRAIN Find & replace function in CM causes a crash
2971983 APD INTERACTIVE Results of Find by Query is incorrect in version 22.1 HF-8
2178156 APD REPORTS Remove the # character for the pins that have duplicate names in the component pin report
2990687 CONCEPT_HDL CORE The 'nconcepthdl' script command takes a long time to complete
2991711 CONCEPT_HDL CORE Saving takes an extreme amount of time
2993105 CONSTRAINT_MGR OTHER Crash with IPC SKILL calls
2997499 CONSTRAINT_MGR OTHER System Capture crashes when user opens CM
3030810 CONSTRAINT_MGR SYSCAP System Capture crashes when you click on a Voltage property that has a conflict (Red) indicator
2860787 PULSE DASHBOARD Medic testcase generation failing (Error: C:/Windows/TEMP/history does not exist)
2826304 PULSE R2PLM-LIBSYNC Need ability to push part level attribute values from Windchill to Pulse Managed Library.
3006874 PULSE R2PLM-LIBSYNC PFM Libsync request to also sync "business group" attributes
2896520 PULSE R2PLM Unable to configure SSO due to hardcoded URL params for Pingfed
2930064 PULSE R2PLM Enable SSO support for Windows Active directory using ADFS for R2PLM
2989057 SYSTEM_CAPTURE CONSTRAINT_MA System Capture crashes when cross-probing from Constraint Manager
2994854 SYSTEM_CAPTURE CONSTRAINT_MA Slowness issue- Editing the blocks in mastermode hangs the syscap
3014399 SYSTEM_CAPTURE DRC Export CSV from Schematic audit report wraps columns for Waived Violation Section
3035989 SYSTEM_CAPTURE FIND_REPLACE Find and Modify netname causes some pins to be disconnected
3036008 SYSTEM_CAPTURE FIND_REPLACE System Capture Find and Replace net names cause many pins to be disconnected
2775636 SYSTEM_CAPTURE HSS_DESIGNEDI system capture: mismatch reported on interface ports of netgroups with correct hierarchy
2587472 SYSTEM_CAPTURE PACKAGER In System Capture SLD, package option for blocks should not be available
2903688 SYSTEM_CAPTURE PACKAGER Undo does not undo refdes change from replacing multi-gate part
3030808 SYSTEM_CAPTURE PACKAGER When Packaging options in System Capture cursor behaviour needs to be changed
3045237 SYSTEM_CAPTURE PACKAGER RMB on functional block > "Packaging Options…" in project explorer window causes Syscap crash
3004270 SYSTEM_CAPTURE PART_MANAGER Unison confirmation popup when updating out of sync parts in Part Manager
3011987 SYSTEM_CAPTURE PART_MANAGER Part manager shows parts in manual sync while property panel shows the parts in sync
2946498 SYSTEM_CAPTURE SYMBOL_GEN Position of some wires in DE-HDL design moved from original location after design migration to System Capture
3047762 SYSTEM_CAPTURE SYMBOL_GEN Importing design from DEHDL to Syscap has error- DSCS-1036 errors.
2985507 SYSTEM_CAPTURE UI In 22.1 ISR009 SysCap shifts position of Navlinks
2947758 SYSTEM_CAPTURE UNIFIED_SEARC Part Number column in Unified Search is hidden when window is undocked and resized
2815584 SYSTEM_DESIGN SDE_EXPORT_SU Subsystems project cannot be exported when site.cpm sets user page border
3001872 SYS_RELIABILITY STRESS_ANALYS Stress analysis is ignoring the part based on BOM_IGNORE property irrespective of its value.
2990723 TDA CORE ALGX300 cannot invoke Team Design Authoring
Cadence Allegro PCB Design helps bring your innovative and bleeding-edge designs to life. The constraint-driven environment provides real-time visual feedback and ensures the functionality and manufacturability of your PCBs while allowing you to keep designing.
OrCAD is a driving force in the PCB design industry. In order to help desingers keep up with the constant pace of change Cadence has been accelerating the pace of innovation delivering a stream of updates and product enhancements to users. OrCAD provides insight into industry-first capabilities made available to customers such as real-time design, DesignTrue DFM, constraint manager, in-design analysis, and more. In July of 1999, OrCAD and its product line were acquired by Cadence Design Systems. OrCAD integrated with Cadence Allegro PCB design software creating a fully scalable solution for solving any level of PCB design challenge.
Cadence PCB Suites and Options 2022
Here we explore the various features of the Cadence PCB Suites and options.
Cadence enables global electronic design innovation and plays an essential role in the creation of today’s integrated circuits and electronics. Customers use Cadence software, hardware, IP and services to design and verify advanced semiconductors, consumer electronics, networking and telecommunications equipment, and computer systems. The company is headquartered in San Jose, Calif., with sales offices, design centers and research facilities around the world to serve the global electronics industry.
Owner: Cadence Design Systems, Inc.
Product Name: Cadence Allegro and OrCAD
Version: 2022.1 HF011 (22.10.011)
Supported Architectures: x64
Website Home Page : www.cadence.com
Languages Supported: english
System Requirements: Windows *
Software Prerequisites: pre-installed Cadence Allegro and OrCAD 2022.1 Base or above
Size: 4.0 Gb
